型号： |
BB721 |
| 标记/丝印/代码/打字： |
|
| 厂家： |
MICRONAS |
| 封装： |
SOD-123/1206 |
| 批号： |
05+ |
| 库存数量： |
0 |
| 所属分类： |
二极管Diodes
变容二极管Variable Capacitance Diodes (Varicaps, Varactors)
单管Single |
| 技术文档PDF： |
在线阅读  |
| |
|
| 在线购买 |
|
|
|
|
BB721 的参数 |
| 反向电压VR
Reverse Voltage |
32V |
| 电容值C
Diode capacitance |
17.5pF-21.5pF |
| @反向电压VR
@Reverse Voltage |
1V |
| 电容值C
Diode capacitance |
1.9pF-2.3pF |
| @反向电压VR
@Reverse Voltage |
28V |
| 电容比
Capacitance ratio |
8.2-9.8 |
| Description & Applications |
Features ? Tuner Diodes ? Silicon epitaxial planar capacitance diodes with very wide effective capacitance variation for tuning the whole range of UHF television bands. ? Two BB721/BB721S tuner diodes in series are used for direct satellite receivers. ? These diodes are available as singles or as matched sets of two or more units according to the tracking condition described in the table of characteristics. ? This diode is also available in SOD-323 case with the type designation BB721S. |
| 描述与应用 |
特点 ?调谐二极管 ?硅外延平面电容的二极管调谐UHF电视频段的整个范围非常广泛有效的电容变化。 ?两个BB721/BB721S用于直接卫星接收机调谐二极管串联。 这些二极管是可以作为单曲或匹配的组中的两个或两个以上的单位，根据在表中描述的特征的跟踪条件。 该二极管也可在SOD-323的类型指定BB721S的情况。 |
| 技术文档PDF下载 |
在线阅读 |
|
|
|
|
|
