RT9162-33CX AO 的参数 |
| 电路数量
Number of Regulators |
1 |
| 输入电压VIN
Voltage - Input |
15V |
| 输出电压VOUT
Voltage - Output |
3.3V |
| 输出电流Io
Current - Output |
400mA/0.4A |
| 最大压降VDO
Voltage - Dropout |
1.2V |
| 带使能脚EN/CE(ON/OFF功能)
With Enable Pin |
无 No |
| 最大耗散功率Pd
Power dissipation |
500mW/0.5W |
| Description & Applications |
300mA Low Dropout Positive Voltage Regulator ;? Low Dropout, Maximum 1.3V at 300mA ?Fast Transient Response ?2% Total Output Regulation ? 0.4% Line Regulation ? 0.4% Load Regulation ?5V to 3.3V Linear Regulator ? Low Voltage Microcontroller, DSF, … etc. PowerSupply ? Linear Regulator for LAN Card and CD-ROM |
| 描述与应用 |
300mA的低漏失正电压稳压器;?低压差，在300mA的最大1.3V ?快速瞬态响应 ?2％的总输出调节 ?0.4％线路调整 ?0.4％的负载调整 ?5V到3.3V线性稳压器 ?低电压微控制器，DSF等POWERSUPPLY ?局域网卡和CD-ROM的线性稳压器 |
